Results for c:\Users\LeCroyUser\Desktop\F1eye00000
Sigtest:
Overall Sigtest Result: Pass!
Mean Unit Interval (ps): 166.663902
Min Time Between Crossovers (ps): 156.763266
Data Rate (Gb/s): 6.0001
Max Peak to Peak Jitter: 20.909753 ps
Total Jitter at BER of 10E-12: 21.221259 ps
Total Jitter at BER of 10E-12 Passes Sigtest Limits!
Minimum eye width: 145.445408 ps
Deterministic Jitter Delta-Delta: 9.000423 ps
Deterministic Jitter Delta-Delta Passes Sigtest Limits!
Random Jitter (RMS): 0.868637 ps
Random Jitter (RMS) Passes Sigtest Limits!
Minimum Transition Eye Voltage: -0.311067 volts
Minimum Transition Eye Voltage Passes Sigtest Limits!
Maximum Transition Eye Voltage: 0.316747 volts
Maximum Transition Eye Voltage Passes Sigtest Limits!
Composit Eye Height: 0.46029
Composit Eye Location: 0.50004
Composit Eye Height Passes Sigtest Limits!
Minimum Transition Eye Voltage Margin Above Eye: 0.202879 volts
Minimum Transition Eye Voltage Margin Above Eye Passes Sigtest Limits!
Minimum Transition Eye Voltage Margin Below Eye: -0.196343 volts
Minimum Transition Eye Voltage Margin Below Eye Passes Sigtest Limits!
Minimum Transition Eye Height: 0.469222 volts

Worst Non Transition Signal Eye
TEMPLATE FILE SETTINGS
Template File: sata_6_0gb \ SATA_6_0Gb_Tx
Nominal Data Rate (bits/sec): 6000000000.0
Target Unit Interval (s): 1.666667e-010
Minimum Time Allowed Between Crossovers (s): 1.4167e-010
Minimum Data For Testing (UI): 100
Ambiguous UI Resolution Method: EYE_AMBIGUOUS_NONE (0)
Tj@E-12 Peak to Peak Jitter Limit (s): 1.1e-010
Dj_dd Peak to Peak Jitter Limit (s): 7.167e-011
CTLE equalization not used
DFE equalization: Tap 1 unused, Tap 2 = 0.0
Sigtest Version: 4.0.23
